UNS S20200 Round Bars, SS 202 Round Bars, AISI SS 202 Stainless Steel 202 Round Bars Supplier, Manufacturer and Exporter in India
Din 1.4373 SS 202 Round Bars, SS UNS S20200 Round Bars, Stainless Steel 202 Round Rods, 202 Stainless Steel 202 Cold Drawn Bars Suppliers in India.
STAINLESS STEEL 202 ROUND BARS DESCRIPTION:
Type 201 Stainless Steel is an austenitic chromium-nickel-manganese stainless steel which was developed to conserve nickel. Type 201 is a lower cost alternative to conventional Cr-Ni stainless steels such as 301 and 304. Nickel is replaced by additions of manganese and nitrogen. It is non-hardenable by thermal treatment, but may be cold worked to high tensile strengths. Type 201 is essentially nonmagnetic in the annealed condition and becomes magnetic when cold worked. Type 201 can be substituted for Type 301 in many applications
STAINLESS STEEL 202 ROUND BARS PROCESSING:
The annealing temperature for Type 201 is between 1850-2000°F. Rapid cooling through the carbide precipitation range (1500 – 800 o F) is necessary to keep the carbides in solution and prevent sensitization. Type 201 is not hardenable by thermal treatment; it is only hardenable by cold working.
STAINLESS STEEL 202 ROUND BARS FORMING:
Type 201 has similar bending, forming and drawing characteristics to Type 301 stainless steel
STAINLESS STEEL 202 ROUND BARS WELDING:
Type 201 can be welded by all conventional methods applied to 18 percent chromium, 8 percent nickel steels. Filler metal of the conventional chromium-nickel analyses can be used. Like other austenitic stainless steels where carbon is not controlled below 0.03%, Type 201 is susceptible to intergranular corrosion in the weld heat affected zone.
STAINLESS STEEL 202 ROUND BARS CORROSION:
Type 201 is resistant to a wide variety of mild to moderately corrosive environments. It has corrosion resistance approaching that of Types 301and has been successfully substituted for 304 in many mild environments.
STAINLESS STEEL 202 ROUND BARS CHEMICAL PROPERTIES:
| Element | Type 201 |
|---|---|
| Carbon | 0.15x |
| Manganese | 5.5 - 7.5 |
| Sulfur | 0.03X |
| Phosphorus | 0.060x |
| Silicon | 1.0 x |
| Chromium | 16 - 18 |
| Nickel | 3.5 -5.5 |
| Nitrogen | 0.25x |
STAINLESS STEEL 202 ROUND BARS MECHANICAL PROPERTIES:
| Type | Yield Strength 0.2% offset (KSI) | Tensile Strength (KSI) | % Elongation (2" Gauge length) |
Hardness Rockwell |
|---|---|---|---|---|
| 201 Ann | 38 min. | 75 min. | 40% min. | HRB 95 max. |
| 201 ¼ Hard | 75 min. | 125 min. | 25.0 min. | 25 – 32 HRC (typical) |
| 201 ½ Hard | 110 min. | 150 min. | 18.0 min. | 32 - 37 HRC (typical) |
| 201 ¾ Hard | 135 min. | 175 min. | 12.0 min. | 37 – 41 HRC (typical) |
| 201 Full Hard | 145 min. | 185 min. | 9.0 min. | 41 – 46 HRC (typical) |
STAINLESS STEEL 202 ROUND BARS PHYSICAL PROPERTIES:
| Density (lb./ in^2) @ RT | 0.283 | |
|---|---|---|
| Modulus of Elasticity in Tension (psi x 10^6) | 28.6 | |
| Specific Heat (BTU/o F/lb.) | 32 to 212 °F | 0.12 |
| Thermal Conductivity (BTU/hr/ft^2/ft) | 212°F | 9.4 |
| Mean Coefficient of Thermal Expansion (in. x 10^-6 per °F) | 32 to 212°F | 8.7 |
| 32 to 600°F | 9.7 | |
| 32 to 1,000°F | 10.2 | |
| Electrical Resistivity (micro ohms - cm) | at 70oF | 69 |
| Melting Point Range (oF) | 2550/2650 | |
| Oxidation Resistance - Continuous Service(oF) | 1550 | |
| Oxidation Resistance - Intermittent Service(oF) | 1500 |
Cold Drawn Stainless steel Wire Round Bars
Application :
Machined Components, Pump Shafts, Valves, Fasteners, Machine Tools, Dairy Equipments, Surgical & Medical Parts, Threaded Bars, Studs, Bolts, Pins, Hinges and Handles.
Condition |
Cold Drawn & Polished |
Cold Drawn, Centre less Ground & Polished |
Cold Drawn, Centre less Ground & Polished (Strain Hardened) |
|---|---|---|---|
Grades |
Alloy 286,Alloy 20, 202, 303, 304, 304L, 310, 316, 316L, 32, 410, 420, 416, 430, 431, 430F , 630, 17-4ph, Duplex steel 2205 |
304, 304L, 316, 316L |
|
Diameter (Size) |
2 mm to 5mm (1/8" to 3/16") |
6mm to 22m (1/4" to 7/8") |
10mm to 40mm (3/8" to 1-1/2") |
Diameter Tolerance |
h9 (Din 671),h11 |
h9 (Din 671) |
h9 (Din 671),h11 |
Length |
3/4/5.6/6 meter |
3/4/5.6/6 meter |
3/4/5.6/6 meter |
Length Tolerance |
-0/+200mm or |
-0/+200mm or |
-0/+200mm |
Peeled Turned Polished Stainless Steel Round Bars and Stainless steel forged Bars:
Condition |
Peeled, Centreless Ground & Polished |
Peeled & Polished |
Peeled |
Forged, |
|---|---|---|---|---|
Grades |
Alloy 286,Alloy 20, 202, 303, 304, 304L, 310, 316, 316L, 32, 410, 420, 416, 430, 431, 430F , 630, 17-7,17-4ph, Duplex steel 2205, Duplex steel 2507 |
304, 304L, 316, 316L, 410, 416, 420, 431, 17-4Ph |
303, 304, 304L, 316, 316L, 410, 416, 420, 431, 17-4 ph |
|
Diameter (Size) |
20mm to 85mm |
85mm to 140mm |
25mm to 140mm |
150mm to 400mm (6 ” to 16 ”) |
Diameter Tolerance |
h9 (Din 671) tolerance |
h11 tolerance |
K12/K13 |
-0mm/+3mm |
Length |
3/4/5.6/6 meter |
3/4/5.6/6 meter |
3/4/5.6/6 meter |
3 meter -5 meter |
Length Tolerance |
-0/+200mm or |
-0/+200mm or |
-0/+1000mm or 500mm (-0 ”/+3 feet or +2 feet) |
-0/+2 meter- |
We export our STAINLESS STEEL 202 ROUND BARS products to Western and Eastern Europe, Saudi Arabia, Bangladesh, United States, United Arab Emirates, Canada, Angola, Argentina, Austria, Azerbaijan, Pakistan, Peru, Chile, Spain, France, United Kingdom, Indonesia, Israel, Iran, Kuwait, Mexico, Malaysia, Nigeria, Serbia, Singapore, Taiwan, Chile, Venezuela, Ecuador, Netherlands, Brazil, Colombia, Ghana, Iran, Denmark, Poland, Australia, Afghanistan, Bahrain, Costa Rica, Egypt, Iraq, Jordan, South Korea, Kazakhstan, Sri Lanka, Lithuania, Norway, Oman, Philippines, Poland, Qatar, Russia, Vietnam, South Africa, Nigeria, Mexico, Turkey, Hungary, Algeria, Belarus, Belgium, Bhutan, Bolivia, Bulgaria, Croatia, Czech Republic, Estonia, Finland, Greece, Italy, Japan, Libya, Romania, Thailand, Trinidad & Tobago,Tunisia, Ukraine, Yemen, Hong Kong, Gabon, China, Portugal, Switzerland, New Zealand, Sweden, Slovakia, Kenya, Lebanon, Morocco, Mongolia etc. We are sure that we also can cover the requirements requested by your company you can email us at harshsteel@ymail.com for your instant requirements.
